DECKING FLOOR SHEET

Profiled Panel Weight

  0.8mm thick    8.72     kg/㎡

  1.0 mm thick   10.90   kg/㎡

  1.2 mm thick    13.08  kg/㎡

Section Moment of Inertia

  0.8mm thick    51.64 cm⁴/m

  1.0mm thick    64.55 cm⁴/m

  1.2mm thick    77.50 cm⁴/m

Section Moment of Resistance

  0.8mm thick    16.56  cm³/m

  1.0mm thick    20.70  cm³/m

  1.2mm thick    24.82  cm3/m

 Profiled Panel Weight

  0.8mm thick    8.37     kg/㎡

  1.0 mm thick   10.47   kg/㎡

  1.2 mm thick   12.56   kg/㎡

Section Moment of Inertia

  0.8mm thick    47.67 cm⁴/m

  1.0mm thick    59.56 cm⁴/m

  1.2mm thick   71.44  cm⁴/m

Section Moment of Resistance

  0.8mm thick    23.29  cm³/m

  1.0mm thick    28.59  cm³/m

  1.2mm thick    34.51  cm3/m

 Profiled Panel Weight

  0.8mm thick    9.13    kg/㎡

  1.0 mm thick  11.41   kg/㎡

  1.2 mm thick   13.69  kg/㎡

Section Moment of Inertia

  0.8mm thick    119.50  cm⁴/m

  1.0mm thick    148.20  cm⁴/m

  1.2mm thick    180.10  cm⁴/m

Section Moment of Resistance

  0.8mm thick    28.54   cm³/m

  1.0mm thick    35.68   cm³/m

  1.2mm thick     42.83  cm3/m

Profiled Panel Weight

   0.8mm thick    10.45  kg/㎡

  1.0 mm thick    13.08  kg/㎡

  1.2 mm thick    15.70  kg/㎡

Section Moment of Inertia

   0.8mm thick    127.50  cm⁴/m

   1.0mm thick    158.20  cm⁴/m

   1.2mm thick    190.10  cm⁴/m

Section Moment of Resistance

   0.8mm thick    33.34  cm³/m

   1.0mm thick    41.69  cm³/m

   1.2mm thick    50.04  cm3/m

 Profiled Panel Weight

  0.8mm thick    11.01   kg/㎡

  1.0 mm thick   13.77   kg/㎡

  1.2 mm thick    16.52  kg/㎡

Section Moment of Inertia

  0.8mm thick    126.20  cm⁴/m

  1.0mm thick    157.70  cm⁴/m

  1.2mm thick    189.20  cm⁴/m

Section Moment of Resistance

  0.8mm thick    32.38   cm³/m

  1.0mm thick     40.47  cm³/m

  1.2mm thick    48.57   cm3/m

Profiled Panel Weight

  0.8mm thick    8.37     kg/㎡

  1.0 mm thick   10.47   kg/㎡

  1.2 mm thick   12.56   kg/㎡

Section Moment of Inertia

  0.8mm thick    18.89  cm⁴/m

  1.0mm thick    23.28  cm⁴/m

  1.2mm thick   28.36   cm⁴/m

Section Moment of Resistance

  0.8mm thick    10.98    cm³/m

  1.0mm thick     13.53   cm³/m

  1.2mm thick     16.48   cm3/m

Profiled Panel Weight

  0.8mm thick    9.57     kg/㎡

  1.0 mm thick   11.97   kg/㎡

  1.2 mm thick   14.36   kg/㎡

Section Moment of Inertia

  0.8mm thick    49.23  cm⁴/m

  1.0mm thick    61.55  cm⁴/m

  1.2mm thick    73.86  cm⁴/m

Section Moment of Resistance

  0.8mm thick    19.41   cm³/m

  1.0mm thick     24.17  cm³/m

  1.2mm thick     28.89  cm3/m

 Profiled Panel Weight

  0.8mm thick    7.96   kg/㎡

  1.0 mm thick   9.92   kg/㎡

  1.2 mm thick   11.91 kg/㎡

Section Moment of Inertia

  0.8mm thick    51.90  cm⁴/m

  1.0mm thick    70.60  cm⁴/m

  1.2mm thick    81.89  cm⁴/m

Section Moment of Resistance

  0.8mm thick    16.86   cm³/m

  1.0mm thick     22.22  cm³/m

  1.2mm thick     28.41  cm3/m

 Profiled Panel Weight

  0.75mm thick    8.20    kg/㎡

  0.9mm thick      9.96    kg/㎡

  1.2 mm thick    13.18   kg/㎡

Section Moment of Inertia

  0.75mm thick  105.00   cm⁴/m

  0.9 mm thick    128.10  cm⁴/m

  1.2mm thick     172.10  cm⁴/m

Section Moment of Resistance

  0.75 mm thick   23.28   cm³/m

  0.9  mm thick    29.57   cm³/m

  1.2mm thick      41.94   cm3/m

Profiled Panel Weight

  0.8mm thick    12.40   kg/㎡

  1.0 mm thick   14.70   kg/㎡

  1.2 mm thick   18.40   kg/㎡

Section Moment of Inertia

  0.8mm thick    98.88    cm⁴/m

  1.0mm thick    124.32  cm⁴/m

  1.2mm thick    148.33  cm⁴/m

Section Moment of Resistance

  0.8mm thick     22.43   cm³/m

  1.0mm thick     27.98   cm³/m

  1.2mm thick     33.72   cm3/m

Profiled Panel Weight

  0.8mm thick    7.62     kg/㎡

  1.0 mm thick   9.53     kg/㎡

  1.2 mm thick   11.43   kg/㎡

Section Moment of Inertia

  0.8mm thick    47.52   cm⁴/m

  1.0mm thick    58.10   cm⁴/m

  1.2mm thick    68.70   cm⁴/m

Section Moment of Resistance

  0.8mm thick     17.90   cm³/m

  1.0mm thick     22.90   cm³/m

  1.2mm thick     28.40   cm3/m

More styles could be customized, please don't hesitate to contact us.
